Support Capabilities List
| Part No. |
Description |
Chapter |
Effectivity |
| 1277M55G01 |
Shroud Air Impigement Manifold
-HPT |
72-53-05 |
CFM56-3 |
| 1277M91G01 |
HPC
Inner Shroud, 3rd Stage |
72-32-07 |
CFM56-3 |
| 1277M91G03 |
HPC
Inner Shroud, 3rd Stage |
72-32-07 |
CFM56-3 |
| 1277M91G05 |
HPC
Inner Shroud, 3rd Stage |
72-32-07 |
CFM56-3 |
| 1282M34P02 |
HPT
Rotor Front Shaft |
72-52-04 |
CFM56-3 |
| 1282M71P01 |
HPT Rotor Front Shaft |
72-52-04 |
CFM56-3 |
| 1285M66G01 |
HPT
Aft Outer Seal Support |
72-51-04 |
CFM56-3 |
| 1317M89G08 |
Linner-Inner,
Comb. Chamber |
72-42-03 |
CFM56-3 |
| 1317M90G04 |
Linner-Outer,
Comb. Chamber |
72-42-04 |
CFM56-3 |
| 1358M63G01 |
HPC
Inner Shroud, 1st Stage |
72-32-07 |
CFM56-3 |
| 1358M63G03 |
HPC
Inner Shroud, 2nd Stage |
72-32-07 |
CFM56-3 |
| 1358M63G07 |
HPC Inner Shroud, 3rd Stage |
72-32-07 |
CFM56-3 |
| 1385M90P01 |
HPT
Rotor Front Shaft |
72-52-04 |
CFM56-3 |
| 1385M90P04 |
HPT
Rotor Front Shaft |
72-52-04 |
CFM56-3 |
| 1441M26P02 |
HPT
Rotor Front Shaft |
72-52-04 |
CFM56-3 |
| 1441M26P03 |
HPT Rotor Front Shaft |
72-52-04 |
CFM56-3 |
| 1558M92G01 |
Compressor Rear Stator Support |
72-41-07 |
CFM56-3 |
| 1558M92G02 |
Compressor Rear Stator Support |
72-41-07 |
CFM56-3 |
| 158M63G03 |
HPC
Inner Shroud, 2nd Stage |
72-32-07 |
CFM56-3 |
| 301-287-119-0 |
Stationary Air/Oil Seal
- Config.
1 |
72-22-11 |
CFM56-3 |
| 301-297-810-0 |
No. 1 Bearing Sleeve |
72-22-12 |
CFM56-3 |
| 301-297-812-0 |
No.
1 Bearing Sleeve |
72-22-12 |
CFM56-3 |
| 301-321-242-0 |
No. 5 Bearing Support |
72-56-02 |
CFM56-3 |
| 301-321-253-0 |
No. 5 Bearing Support |
72-56-02 |
CFM56-3 |
| 301-321-258-0 |
No. 5 Bearing Support |
72-56-02 |
CFM56-3 |
| 301-321-259-0 |
No. 5 Bearing Support |
72-56-02 |
CFM56-3 |
| 301-321-612-0 |
Midstream Fairing |
72-56-04 |
CFM56-3 |
| 301-330-046-0 |
LPT Shaft |
72-55-01 |
CFM56-3 |
| 301-330-047-0 |
LPT Shaft |
72-55-01 |
CFM56-3 |
| 301-330-061-0 |
LPT Shaft |
72-55-01 |
CFM56-3 |
| 301-330-065-0 |
LPT Shaft |
72-55-01 |
CFM56-3 |
| 301-330-066-0 |
LPT Shaft |
72-55-01 |
CFM56-3 |
| 301-330-067-0 |
LPT Shaft |
72-55-01 |
CFM56-3 |
| 301-330-618-0 |
LPT Stub Shaft |
72-55-02 |
CFM56-3 |
| 301-330-619-0 |
LPT Stub Shaft |
72-55-02 |
CFM56-3 |
| 301-330-623-0 |
LPT Stub Shaft |
72-55-02 |
CFM56-3 |
| 301-330-624-0 |
LPT Stub Shaft |
72-55-02 |
CFM56-3 |
| 301-330-626-0 |
LPT Stub Shaft |
72-55-02 |
CFM56-3 |
| 301-330-811-0 |
Rear Rotating Air Seal |
72-55-04 |
CFM56-3 |
| 301-330-814-0 |
Rear Rotating Air Seal |
72-55-04 |
CFM56-3 |
| 301-330-908-0 |
Rear Rotating Air/Oil Seal |
72-55-04 |
CFM56-3 |
| 301-330-909-0 |
Rear Rotating Air/Oil Seal |
72-55-04 |
CFM56-3 |
| 301-331-121-0 |
Disk-LPT Stg. 1 |
72-54-03 |
CFM56-3 |
| 301-331-124-0 |
Disk-LPT Stg. 1 |
72-54-03 |
CFM56-3 |
| 301-331-125-0 |
Disk-LPT Stg. 1 |
72-54-03 |
CFM56-3 |
| 301-331-126-0 |
Disk-LPT Stg. 1 |
72-54-03 |
CFM56-3 |
| 301-331-127-0 |
Disk-LPT Stg. 1 |
72-54-03 |
CFM56-3 |
| 301-331-221-0 |
Disk-LPT Stg. 2 |
72-54-03 |
CFM56-3 |
| 301-331-224-0 |
Disk-LPT Stg. 2 |
72-54-03 |
CFM56-3 |
| 301-331-225-0 |
Disk-LPT Stg. 2 |
72-54-03 |
CFM56-3 |
| 301-331-226-0 |
Disk-LPT Stg. 2 |
72-54-03 |
CFM56-3 |
| 301-331-227-0 |
Disk-LPT Stg. 2 |
72-54-03 |
CFM56-3 |
| 301-331-318-0 |
Disk-LPT Stg. 3 |
72-54-03 |
CFM56-3 |
| 301-331-321-0 |
Disk-LPT Stg. 3 |
72-54-03 |
CFM56-3 |
| 301-331-322-0 |
Disk-LPT Stg. 3 |
72-54-03 |
CFM56-3 |
| 301-331-419-0 |
Disk-LPT Stg. 4 |
72-54-03 |
CFM56-3 |
| 301-331-425-0 |
Disk-LPT Stg. 4 |
72-54-03 |
CFM56-3 |
| 301-331-427-0 |
Disk-LPT Stg. 4 |
72-54-03 |
CFM56-3 |
| 301-331-429-0 |
Disk-LPT Stg. 4 |
72-54-03 |
CFM56-3 |
| 301-334-416-0 |
No. 4 Bearing Fwd Rotating
Oil Seal |
72-55-14 |
CFM56-3 |
| 301-334-417-0 |
No. 4 Bearing Fwd Rotating
Oil Seal |
72-55-14 |
CFM56-3 |
| 301-350-234-0 |
Cover, Oil-Inlet |
72-56-06 |
CFM56-3 |
| 301-350-235-0 |
Cover, Oil-Inlet |
72-56-06 |
CFM56-3 |
| 301-350-238-0 |
Cover, Oil-Inlet |
72-56-06 |
CFM56-3 |
| 301-350-239-0 |
Cover, Oil-Inlet |
72-56-06 |
CFM56-3 |
| 301-350-240-0 |
Cover, Oil-Inlet |
72-56-06 |
CFM56-3 |
| 301-475-207-0 |
No. 1 Bearing Oil Baffle |
72-22-14 |
CFM56-3 |
| 301-484-001-0 |
Rear Rotating Air/Oil Seal -
Config. 2 |
72-55-04 |
CFM56-3 |
| 301-555-227-0 |
Shroud Support-LPT |
72-54-04 |
CFM56-3 |
| 301-555-228-0 |
Shroud Support-LPT |
72-54-04 |
CFM56-3 |
| 305-056-106-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-109-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-110-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-111-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-112-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-115-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-116-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-117-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-118-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-119-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-120-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-121-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-122-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-123-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-056-124-0 |
Rotor Support-LPT |
72-54-05 |
CFM56-3 |
| 305-078-639-0 |
Case Assy-LPT Rear |
72-54-07 |
CFM56-3 |
| 305-078-642-0 |
Case Assy-LPT Rear |
72-54-07 |
CFM56-3 |
| 305-078-643-0 |
Case Assy-LPT Rear |
72-54-07 |
CFM56-3 |
| 305-078-648-0 |
Case Assy-LPT Rear |
72-54-07 |
CFM56-3 |
| 305-078-651-0 |
Case Assy-LPT Rear |
72-54-07 |
CFM56-3 |
| 305-078-652-0 |
Case Assy-LPT Rear |
72-54-07 |
CFM56-3 |
| 305-078-653-0 |
Case Assy-LPT Rear |
72-54-07 |
CFM56-3 |
| 305-078-654-0 |
Case Assy-LPT Rear |
72-54-07 |
CFM56-3 |
| 305-097-903-0 |
Bumper Bearing |
72-55-13 |
CFM56-3 |
| 305-098-405-0 |
Fwd. Rotating Oil Seal |
72-55-12 |
CFM56-3 |
| 305-098-406-0 |
Fwd. Rotating Oil Seal |
72-55-12 |
CFM56-3 |
| 305-098-407-0 |
Fwd. Rotating Oil Seal |
72-55-12 |
CFM56-3 |
| 305-396-303-0 |
Oil Separator Ring |
72-22-05 |
CFM56-3 |
| 305-439-401-0 |
Stationary Air/Oil Seal |
72-22-11 |
CFM56-3 |
| 305-439-402-0 |
Stationary Air/Oil Seal |
72-22-11 |
CFM56-3 |
| 334-007-196-0 |
Center Vent Tube |
72-55-06 |
CFM56-3 |
| 335-003-304-0 |
No. 1 Bearing Support Assembly |
72-22-02 |
CFM56-3 |
| 335-003-305-0 |
No. 1 Bearing Support Assembly |
72-22-02 |
CFM56-3 |
| 335-006-405-0 |
Fan Shaft |
72-22-01 |
CFM56-3 |
| 335-006-407-0 |
Fan Shaft |
72-22-01 |
CFM56-3 |
| 335-006-414-0 |
Fan Shaft |
72-22-01 |
CFM56-3 |
| 335-006-509-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-511-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-512-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-513-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-514-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-515-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-516-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-517-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-518-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-519-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-3 |
| 335-006-607-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-609-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-610-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-611-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-612-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-613-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-614-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-615-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-616-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-617-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-619-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-620-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-621-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-622-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-623-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-624-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-625-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-626-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-627-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-628-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-629-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-630-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-631-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-632-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-633-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-634-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-3 |
| 335-006-708-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-709-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-710-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-711-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-714-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-716-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-717-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-718-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-719-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-720-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-721-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-722-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-723-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-724-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-725-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-726-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-727-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-728-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-729-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-730-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-731-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-732-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-733-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-006-734-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-3 |
| 335-009-113-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-117-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-118-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-122-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-123-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-124-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-125-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-126-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-127-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-129-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-130-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-131-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-132-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-133-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-134-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-135-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-136-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-137-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-154-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-155-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-156-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-157-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-158-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-159-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-160-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-009-161-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-3 |
| 335-010-102-0 |
No. 2 Bearing Support Assembly |
72-22-03 |
CFM56-3 |
| 335-010-104-0 |
No. 2 Bearing Support Assembly |
72-22-03 |
CFM56-3 |
| 335-011-208-0 |
Spinner Rear Cone |
72-21-05 |
CFM56-3 |
| 335-030-701-0 |
Housing, Inner and Outer
Radial Drive Shaft |
72-23-05 |
CFM56-3 |
| 335-030-701-0 |
Housing, Inner and Outer
Radial Drive Shaft |
72-23-05 |
CFM56-3 |
| 335-106-402-0 |
Spinner Front Cone |
72-21-05 |
CFM56-3 |
| 335-192-202-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-7 |
| 335-192-203-0 |
Vane Assy-Fan Booster, Stg. 2 |
72-21-09 |
CFM56-7 |
| 335-293-011-0 |
No. 1 Bearing Housing |
72-22-04 |
CFM56-3 |
| 335-305-000-0 |
Support, Bearing |
72-62-04 |
CFM56-3 |
| 335-305-600-0 |
Support, Bearing |
72-62-04 |
CFM56-3 |
| 335-305-601-0 |
Support, Bearing |
72-62-04 |
CFM56-3 |
| 335-352-001-0 |
Fan/Booster Centering Shroud |
72-21-17 |
CFM56-3 |
| 340-001-307-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-7 |
| 340-001-308-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-7 |
| 340-001-309-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-7 |
| 340-001-310-0 |
Vane Assy-Fan Booster, Stg. 1 |
72-21-09 |
CFM56-7 |
| 340-058-302-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-7 |
| 340-058-303-0 |
Vane Assy-Fan Booster, Stg. 3 |
72-21-09 |
CFM56-7 |
| 340-058-402-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-7 |
| 340-058-404-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-7 |
| 340-058-405-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-7 |
| 340-058-406-0 |
Vane Assy-Fan Booster, Stg. 4 |
72-21-09 |
CFM56-7 |
| 85M66G01 |
HPT Aft Outer Seal Support |
72-51-04 |
CFM56-3 |
| 85M66G02 |
HPT Aft Outer Seal Support |
72-51-04 |
CFM56-3 |
| 85M66G04 |
HPT Aft Outer Seal Support |
72-51-04 |
CFM56-3 |
| 85M66G05 |
HPT Aft Outer Seal Support |
72-51-04 |
CFM56-3 |
| 9336M78G01 |
No. 3 Brng. Fwd Stationary
Oil Seal - Config. 1 |
72-23-19 |
CFM56-3 |
| 9339M40G01 |
No. 3 Brng. Fwd Stationary
Oil Seal - Config. 2 |
72-23-19 |
CFM56-3 |
| 9339M40G03 |
No. 3 Brng. Fwd Stationary
Oil Seal - Config. 2 |
72-23-19 |
CFM56-3 |
| 9339M40G04 |
No. 3 Brng. Fwd Stationary
Oil Seal - Config. 2 |
72-23-19 |
CFM56-3 |
| 9513M16G04 |
HPT Shroud Air Impigement
Manifold |
72-53-05 |
CFM56-3 |
| 9514M72P03 |
HPT Rotor Front Shaft |
72-52-04 |
CFM56-3 |
| 9523M17G10 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9523M17G11 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9523M17G12 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9523M17G13 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9523M17G14 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9523M17G15 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9529M99G02 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9529M99G03 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9529M99G04 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9529M99G05 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9529M99G07 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9529M99G08 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9529M99G09 |
Combustion Case |
72-41-01 |
CFM56-3 |
| 9969M93G06 |
Compressor Rear Stator Support |
72-41-07 |
CFM56-3 |
| 9992M65G06 |
HPC Inner Shroud, 1st Stage |
72-32-07 |
CFM56-3 |
| 9992M65G08 |
HPC Inner Shroud, 1st Stage |
72-32-07 |
CFM56-3 |
| 9992M65G10 |
HPC Inner Shroud, 1st Stage |
72-32-07 |
CFM56-3 |
| 9994M18G03 |
HPC Inner Shroud, 2nd Stage |
72-32-07 |
CFM56-3 |
| 9994M18G05 |
HPC Inner Shroud, 2nd Stage |
72-32-07 |
CFM56-3 |
| 9994M18G07 |
HPC Inner Shroud, 2nd Stage |
72-32-07 |
CFM56-3 |
| 9994M19G03 |
HPC Inner Shroud, 3rd Stage |
72-32-07 |
CFM56-3 |
| |
|
|
Back To Top |
| Part No. |
Description |
Chapter |
Effectivity |
| 436315 |
Stator, 5th Stage |
72-33-56 |
JT8D |
| 442435-001 |
Support, No. 5 Bearing Seal |
72-52-11 |
JT8D |
| 446314 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 466092 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 468559 |
Heat Shield, No. 5 Bearing |
72-52-13 |
JT8D |
| 468560 |
Heat Shield, No. 5 Bearing |
72-52-13 |
JT8D |
| 473667 |
Heat Shield, No. 4 Bearing |
72-37-10 |
JT8D |
| 478094 |
Duct, Fan - Rear Compressor |
72-34-05 |
JT8D |
| 478761 |
Tank Assy, Lubrication Oil |
72-61-65 |
JT8D |
| 479197 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 479927 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 479929 |
Spacer-Compressor, 4 to 5th Stage |
72-33-43 |
JT8D |
| 480205 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D |
| 480231 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 480232 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 481004 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 481859 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 481860 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 482177 |
Tube-Seal, Rear Compressor |
72-36-19 |
JT8D |
| 482179 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 482469 |
Spacer-Compressor, 2 to 3rd Stage |
72-33-42 |
JT8D |
| 482471 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 483281 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 483506 |
Disk-Compressor, 6th Stage |
72-33-37 |
JT8D |
| 483603 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 483614 |
Air Seal Ring, No. 2 Bearing |
72-34-13 |
JT8D |
| 483615 |
Air Seal Ring, No. 2 Bearing |
72-34-13 |
JT8D |
| 483799 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 484088 |
Air Seal Ring, Turb. - 4th Stage Outer |
72-53-61 |
JT8D |
| 484852 |
Seal, 7th Stage |
72-36-22 |
JT8D |
| 484907 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 489040 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 489042 |
Lock-Blade, 1st Stage |
72-33-15 |
JT8D |
| 489045 |
Fan Case, Front |
72-33-66 |
JT8D |
| 489106 |
Duct Segment, Fan & Turb. Exhaust |
72-54-11 |
JT8D |
| 489442 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 491338 |
Seal Assy, No. 3 Bearing |
72-34-40 |
JT8D |
| 491653 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 492725 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 492726 |
Air Seal Ring, No. 4 Bearing |
72-36-80 |
JT8D |
| 493177 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 493179 |
Duct Segment, Fan Turbine Inner |
72-71-05 |
JT8D |
| 493416-002 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 494374 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 494903 |
Disk-Compressor, 3rd Stage |
72-33-34 |
JT8D |
| 494904 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 494905 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D |
| 494906 |
Disk-Compressor, 6th Stage |
72-33-37 |
JT8D |
| 495440 |
Oil Nozzle, No. 2 & No. 3 Bearing |
72-34-09 |
JT8D |
| 496149-001 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 496150-001 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 496508 |
Fan Exit Case |
72-33-83 |
JT8D |
| 496830 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 496908 |
Disk-Compressor, 8th Stage |
72-36-42 |
JT8D |
| 496909 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 496910 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 496911 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 496912 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 496913 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 5000184-01 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 5000184-02 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 5000186-01 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 5000186-02 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 5000415-01 |
Disk-Compressor, 1.5 Stage |
72-33-32 |
JT8D-200 |
| 5000415-02 |
Disk-Compressor, 1.5 Stage |
72-33-32 |
JT8D-200 |
| 5000415-03 |
Disk-Compressor, 1.5 Stage |
72-33-32 |
JT8D-200 |
| 5000449-01 |
Combustion Chamber |
72-41-14 |
JT8D-200 |
| 5000449-02 |
Combustion Chamber |
72-41-14 |
JT8D-200 |
| 5000449-05 |
Combustion Chamber |
72-41-14 |
JT8D-200 |
| 5000450-01 |
Combustion Chamber |
72-41-14 |
JT8D-200 |
| 5000450-026 |
Combustion Chamber |
72-41-14 |
JT8D-200 |
| 5000450-05 |
Combustion Chamber |
72-41-14 |
JT8D-200 |
| 5000450-06 |
Combustion Chamber |
72-41-14 |
JT8D-200 |
| 5000480-021 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5000480-03 |
Support, Turbine Stator |
72-51-01 |
JT8D-200 |
| 5000480-04 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5000907-01 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D-200 |
| 5000922-01 |
Spacer-Compressor |
72-36-11 |
JT8D-200 |
| 5000947-01 |
Shaft, Turb - Rear Comp Drive (T1) |
72-52-03 |
JT8D |
| 5001080-01 |
Duct Segment, Fan Exh, Upper, Rear |
72-55-08 |
JT8D |
| 5001081-01 |
Duct Segment, Fan Exh, Lower, Rear |
72-55-08 |
JT8D |
| 5001647-01 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D |
| 5001798-01 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 5001815-01 |
Disk-Compressor, 1.5 Stage |
72-33-32 |
JT8D-200 |
| 5001844-01 |
Spacer-Turb, Air Sealing Ring |
72-53-52 |
JT8D-200 |
| 5001946-01 |
Duct, Fan Exhaust Outer Rear |
72-55-05 |
JT8D-200 |
| 5001946-04 |
Duct, Fan Exhaust Outer Rear |
72-55-05 |
JT8D-200 |
| 5002233-01 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5002235-01 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5002235-02 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5002235-021 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5002349-01 |
Ring, Air Seal, Turbine - 3rd Stage |
72-53-57 |
JT8D |
| 5002350-01 |
Ring, Air Seal, Turbine - 4th Stage |
72-53-58 |
JT8D |
| 5002572-01 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 5002648-01 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D-200 |
| 5002683-01 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 5002684-01 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 500281 |
Air Seal, 2nd Stage Turb. Shroud |
72-53-56 |
JT8D |
| 5002905-01 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D-200 |
| 5002947-01 |
Air Seal-Turbine, 2nd Stage |
72-53-26 |
JT8D |
| 5002947-021 |
Air Seal-Turbine, 2nd Stage |
72-53-26 |
JT8D |
| 5002948-01 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 5002949-01 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 5003103-01 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 5003104-01 |
Disk-Turbine, 4th Stage |
72-53-15 |
JT8D |
| 5003444-01 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 5003446-01 |
Fan Case, Front |
72-33-66 |
JT8D |
| 5003446-02 |
Fan Case, Front |
72-33-66 |
JT8D |
| 5003530-01 |
Ring, Air Seal, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 5003530-021 |
Ring, Air Seal, Turbine - 2nd Stage |
72-53-59 |
JT8D |
| 5003531-01 |
Ring, Air Seal, Turbine - 3rd Stage |
72-53-57 |
JT8D |
| 5003532-01 |
Ring, Air Seal, Turbine - 4th Stage |
72-53-58 |
JT8D |
| 5003534-01 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 5003538-01 |
Case, Turbine Rear |
72-53-51 |
JT8D |
| 5003538-021 |
Case, Turbine Rear |
72-53-51 |
JT8D |
| 5003601-01 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 5003601-021 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 5003603-01 |
Air Seal Ring, Turb. - 4th Stage Outer |
72-53-61 |
JT8D |
| 5003613-01 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 5003656-01 |
Air Seal Ring, Turb. - 2nd Stage Outer |
72-36-59 |
JT8D |
| 5003658-01 |
Air Seal Ring, Turb. - 4th Stage Outer |
72-53-61 |
JT8D |
| 5003746-01 |
Hub-Turbine, 4th Stage |
72-53-19 |
JT8D |
| 5003746-02 |
Hub-Turbine, 4th Stage |
72-53-19 |
JT8D |
| 5004021-01 |
Air Seal Ring, No. 4 Bearing |
72-36-80 |
JT8D-200 |
| 5004021-02 |
Air Seal Ring, No. 4 Bearing |
72-36-80 |
JT8D |
| 5004022-01 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 5004027-01 |
Duct Assy, Fan & Turb. Exhaust |
72-55-02 |
JT8D |
| 5004027-02 |
Duct Assy, Fan & Turb. Exhaust |
72-55-02 |
JT8D |
| 5004028-01 |
Guide, Fan & Turbine Exh Duct |
72-55-10 |
JT8D |
| 5004028-02 |
Guide, Fan & Turbine Exh Duct |
72-55-10 |
JT8D |
| 5004049-01 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5004049-02 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5004049-021 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5004049-022 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5004049-023 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5004049-03 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5004049-031 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5004049-032 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5004049-033 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 5004301-01 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 5004307-01 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 5004307-02 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 5004307-03 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 5004307-04 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 5004307-05 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 5004307-06 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 5004307-07 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 5004307-08 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 5004307-09 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 500507 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 5005201-01 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 5005325-01 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 5005392-01 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 5005394-02 |
Fan Case, Front |
72-33-66 |
JT8D |
| 5005599-01 |
Duct Assy, Fan Diffuser |
72-38-01 |
JT8D-200 |
| 5005613-01 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D-200 |
| 5005769-01 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 5005773-01 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 5005951-01 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 5006007-01 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D-200 |
| 5006007-02 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 5006101-01 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 5006181-01 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 5006232-01 |
Duct Guide, Fan & Turb. Exhaust |
72-54-12 |
JT8D |
| 5006376-01 |
Duct, Fan Exhaust Outer Rear |
72-55-05 |
JT8D-200 |
| 5006471-01 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 5006586-01 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 500734 |
Support-Front Accessory Drive |
72-21-01 |
JT8D |
| 500870 |
Fan Exit Case |
72-33-83 |
JT8D |
| 502075 |
Stator, 5th Stage |
72-33-56 |
JT8D |
| 502502 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 502694 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 502792 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 502793 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 504027-001 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 504101 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 504385 |
Ring, Air Seal, Turbine - 3rd Stage |
72-53-57 |
JT8D |
| 504386 |
Ring, Air Seal, Turbine - 4th Stage |
72-53-58 |
JT8D |
| 506380 |
Tank Assy, Lubrication Oil |
72-61-65 |
JT8D |
| 511216-002 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 511738 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 512595 |
Spacer-Compressor, 2 to 3rd Stage |
72-33-42 |
JT8D |
| 513835 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 513838 |
Lock-Blade, 1st Stage |
72-33-15 |
JT8D |
| 515201 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 518945 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 519584 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 519585 |
Stator, 5th Stage |
72-33-56 |
JT8D |
| 520211 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 520451 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 520504 |
Hub-Turbine, 4th Stage |
72-53-18(19) |
JT8D |
| 520602 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 521011 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 521040 |
Tube-Seal, Rear Compressor |
72-36-19 |
JT8D |
| 521041 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 521088 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 521316 |
Oil Seal Ring, No. 4 Bearing |
72-37-08 |
JT8D |
| 521372 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 522190 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 522194 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 522196 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 522198 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 522787 |
Ring, Air Seal, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 522788 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 523702 |
Duct Segment, Fan & Turb. Exhaust |
72-54-11 |
JT8D |
| 523704 |
Duct Segment, Fan & Turb. Exhaust |
72-54-11 |
JT8D |
| 523798 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 524154 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 524857 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 525084 |
Spacer-Compressor, 2 to 3rd Stage |
72-33-42 |
JT8D |
| 525204 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 525819 |
Support, No. 5 Bearing Seal |
72-52-11 |
JT8D |
| 525838 |
Lock-Blade, 1st Stage |
72-33-15 |
JT8D |
| 528161 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 528516 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 529077 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 529152 |
Spacer-Compressor, 4 to 5th Stage |
72-33-43 |
JT8D |
| 529153 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 529154 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 529155 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 529222-001 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 529224-001 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 529473 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 529855 |
Heat Shield, No. 5 Bearing |
72-52-13 |
JT8D |
| 530007 |
Case, Diffuser |
72-37-01 |
JT8D |
| 531094-001 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 531893 |
Duct, Fan - Rear Compressor |
72-34-08 |
JT8D |
| 537625-001 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 537849 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 538604-002 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 538636-002 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 538638 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 538639 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 538953 |
Spacer, Turbine Rotor |
72-53-21 |
JT8D |
| 538955 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 538956 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 539002 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 539003 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 539004 |
Hub-Turbine, 4th Stage |
72-53-18(19) |
JT8D |
| 539461 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D |
| 539770-002 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 540503 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 540683 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 540995 |
Duct, Fan - Rear Compressor |
72-34-08 |
JT8D |
| 540997 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 541057 |
Duct-Fan, Diffuser, Outer |
72-38-01 |
JT8D |
| 541063 |
Case, Turbine Rear |
72-53-51 |
JT8D |
| 542060 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 542155 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 542261 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 542470 |
Case, Diffuser |
72-37-01 |
JT8D |
| 542471 |
Case, Diffuser |
72-37-01 |
JT8D |
| 542472 |
Case, Diffuser |
72-37-01 |
JT8D |
| 542473 |
Case, Diffuser |
72-37-01 |
JT8D |
| 542487 |
Case, Diffuser |
72-37-01 |
JT8D |
| 542489 |
Case, Diffuser |
72-37-01 |
JT8D |
| 542573 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 544779 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 544781 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 545123-001 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 547060 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 547337 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 547448 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 553566 |
Duct Segment, Fan Turbine Inner |
72-71-05 |
JT8D |
| 553577 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 553598 |
Duct Segment, Fan & Turb. Exhaust |
72-54-11 |
JT8D |
| 553599 |
Duct Segment, Fan & Turb. Exhaust |
72-54-11 |
JT8D |
| 553626 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 553626-001 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 554815-001 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 555117 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 555119 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 555637 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 555638 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 556582 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 556973 |
Heatshield, Inner-No. 4 & 5 Bearing |
72-41-01 |
JT8D |
| 557340 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 557341 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 557342 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 557343 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 557357 |
Oil Nozzle, No. 2 & No. 3 Bearing |
72-34-09 |
JT8D |
| 557970 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 558671 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 559523 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 564845 |
Fan Case, Front |
72-33-66 |
JT8D |
| 564846 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 564908-001 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 564909-001 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 565016 |
Tank Assy, Lubrication Oil |
72-61-65 |
JT8D |
| 565482 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 565483 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 565698 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 565744 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 565759 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 567172 |
Shroud Assy, 2nd Stage |
72-53-56 |
JT8D |
| 567173 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 567174 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 567649 |
Case, Turbine Front |
72-51-02 |
JT8D |
| 567656 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 567852 |
Shroud, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 567853 |
Shroud, Turbine - 3rd Stage |
72-53-57 |
JT8D |
| 567854 |
Shroud, Turbine - 4th Stage |
72-53-58 |
JT8D |
| 568212 |
Case, Diffuser |
72-37-01 |
JT8D |
| 568214 |
Case, Diffuser |
72-37-14 |
JT8D |
| 568268 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 568317 |
Case, Diffuser |
72-37-01 |
JT8D |
| 568323 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 568324 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 568327 |
Ring, Air Seal, Turbine - 4th Stage |
72-53-58 |
JT8D |
| 568328 |
Ring, Air Seal, Turbine - 3rd Stage |
72-53-57 |
JT8D |
| 569574 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 569575 |
Stator, 5th Stage |
72-33-56 |
JT8D |
| 570280 |
Spacer-Compressor, 2 to 3rd Stage |
72-33-42 |
JT8D |
| 570302 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 570402 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 570403 |
Spacer-Compressor, 2 to 3rd Stage |
72-33-42 |
JT8D |
| 570554 |
Case, Diffuser |
72-37-01 |
JT8D |
| 570583 |
Case, Diffuser |
72-37-01 |
JT8D |
| 571579 |
Spacer-Compressor, 2 to 3rd Stage |
72-33-42 |
JT8D |
| 571581 |
Spacer-Compressor, 2 to 3rd Stage |
72-33-42 |
JT8D |
| 572286 |
Shaft, Turb - Rear Comp Drive (T1) |
72-52-03 |
JT8D |
| 572670 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 572674 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 572682 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 572688 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 572689 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 572690 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 575673 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 575674 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 575675 |
Stator, 5th Stage |
72-33-56 |
JT8D |
| 576777 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 577066 |
Air Seal, Compressor - 2nd Stage |
72-33-16 |
JT8D |
| 577084 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 577618 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 578001 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 578059 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 578272 |
Shroud Assy, 2nd Stage |
72-53-56 |
JT8D |
| 578352 |
Shroud, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 578372 |
Shroud Assy, 2nd Stage |
72-53-56 |
JT8D |
| 578373 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 578374 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 578452 |
Shroud, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 578453 |
Shroud, Turbine - 3rd Stage |
72-53-57 |
JT8D |
| 578454 |
Shroud, Turbine - 4th Stage |
72-53-58 |
JT8D |
| 578481 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 579093 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 579095 |
Fan Case, Front |
72-33-66 |
JT8D |
| 579114 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 579115 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 579281 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 579672 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 579861 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 581022 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 583385 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 583423 |
Disk-Compressor, 3rd Stage |
72-33-34 |
JT8D |
| 584322 |
Duct-Fan, Diffuser, Outer |
72-38-01 |
JT8D |
| 584861 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 586906 |
Disk-Compressor, 6th Stage |
72-33-37 |
JT8D |
| 586911 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 587052 |
Shroud, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 587072 |
Shroud Assy, 2nd Stage |
72-53-56 |
JT8D |
| 587205 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D |
| 587350 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 587501 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 587572 |
Heat Shield, No. 4 Bearing |
72-37-10 |
JT8D |
| 587573 |
Heat Shield, No. 4 Bearing |
72-37-10 |
JT8D |
| 587837 |
Case, Diffuser |
72-37-01 |
JT8D |
| 589149 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 589470 |
Fan Exit Case |
72-33-83 |
JT8D |
| 590373 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 590383 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 590384 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 591573 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 591804 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 591853 |
Fan Case, Front |
72-33-66 |
JT8D |
| 591857 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 591915 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 593074 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 593138 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 593159 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 593161 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 593162 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 593212 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 593217 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 593258 |
Case, Diffuser |
72-37-01 |
JT8D |
| 593563 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 593565 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 594295 |
Case, Turbine Rear |
72-53-51 |
JT8D |
| 594296 |
Ring, Air Seal, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 594301 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 596021 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 596517 |
Case, Turbine Front |
72-51-02 |
JT8D |
| 596705 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D |
| 596773 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 596774 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 596810 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 596812 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 596814 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 596881 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 597615 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 597616 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 597755 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 597756 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 599410 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 599930 |
Case, Diffuser |
72-37-01 |
JT8D |
| 611106 |
Disk-Compressor, 6th Stage |
72-33-37 |
JT8D |
| 611626 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 613782 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 613783 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 614334 |
Outlet Duct Assy |
72-51-15 |
JT8D |
| 614344 |
Duct Assy, Combustion Chamber |
72-51-15 |
JT8D |
| 615141 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 615142 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 615396 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 615398 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 615636 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 615640 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 615641 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 615647 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 615689 |
Duct Segment, Fan Turbine Inner |
72-71-05 |
JT8D |
| 615693 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 615695 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 616002 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 616010 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 616011 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 616037 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 616110 |
Case, Diffuser |
72-37-01 |
JT8D |
| 616288 |
Duct-Fan, Diffuser, Outer |
72-38-01 |
JT8D |
| 616315 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 616612 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 616645 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 618037 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 618039 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 618703 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 618774 |
Air Seal Ring, No. 4 Bearing |
72-36-80 |
JT8D |
| 623303 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 623506 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 624325 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 624326 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 624327 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 625071 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 625658 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 625660 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 625665 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 625668 |
Air Seal Ring, No. 4 Bearing |
72-36-80 |
JT8D |
| 625937 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 626042 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 626371 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 626389 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 626390 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 626391 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 626392 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 626393 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 626394 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 626603 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 626975 |
Ring, Air Seal, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 626976 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 626977 |
Air Seal Ring, Turb. - 4th Stage Outer |
72-53-61 |
JT8D |
| 627852 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 628116 |
Housing Assy, No. 3 Bearing |
72-34-32 |
JT8D |
| 628209 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 628748 |
Inner Outlet Duct |
72-51-22 |
JT8D |
| 628765 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 628772 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 628778 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 628790 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 629057 |
Seal Assy, No. 3 Bearing |
72-34-40 |
JT8D |
| 629158 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 629160 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 629404 |
Hub-Turbine, 4th Stage |
72-53-18(19) |
JT8D |
| 629547 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D |
| 633386 |
Spacer-Turbine, 3 to 4th Stage |
72-53-22 |
JT8D |
| 633413 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 633730 |
Support-Front Accessory Drive |
72-21-01 |
JT8D |
| 633732 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 633758 |
Support-Front Accessory Drive |
72-21-01 |
JT8D |
| 633760 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 633894 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 634332 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 634603 |
Case, Diffuser |
72-37-01 |
JT8D |
| 634605 |
Case, Diffuser |
72-37-01 |
JT8D |
| 634607 |
Duct-Fan, Diffuser, Outer |
72-38-01 |
JT8D |
| 634748 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D |
| 636445 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 636990 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 636993 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 637816 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 638229 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 639020 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 639021 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 639024 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 639409 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 639410 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 639602 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 639604 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 639611 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 639616 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 639617 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 640329 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 640501 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 640601 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 640670 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 640677 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 641013 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 641082 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 641083 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 642013 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 642398 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 642399 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 642774 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 642776 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 642822 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 642823 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 642824 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 642969 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 647564 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 647821 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 648028 |
Spacer, Turbine Rotor |
72-53-21 |
JT8D |
| 648039 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 648962 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 649983 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 649984 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 650327 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 650403 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 650566 |
Case, Diffuser |
72-37-01 |
JT8D |
| 650568 |
Case, Diffuser |
72-37-01 |
JT8D |
| 650782 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 652493 |
Case, Diffuser |
72-37-01 |
JT8D |
| 652494 |
Case, Diffuser |
72-37-01 |
JT8D |
| 652529 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 652530 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 652531 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 652532 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 652533 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 653130 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D |
| 653585 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D |
| 654342 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 655882 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 655985 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 655987 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 656238 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 656239 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 656774 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 656805 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 656806 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 656813 |
Spacer-Compressor, 2 to 3rd Stage |
72-33-42 |
JT8D |
| 656814 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 656815 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 656816 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 656817 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 656818 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 656819 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 656820 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 656860 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 657346 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 657347 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 657841 |
Oil Seal Ring, No. 4 Bearing |
72-37-08 |
JT8D |
| 657994 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 658472 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 660072 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 660469 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 660515 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 660649 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 660650 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 660653 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 660655 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 660656 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 660657 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 660658 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 660958 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 661372 |
Heatshield, Inner-No. 4 & 5 Bearing |
72-41-01 |
JT8D |
| 662147 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 662148 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 662149 |
Housing Assy, No. 6 Bearing |
72-54-19 |
JT8D |
| 662150 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 662608 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 662611 |
Duct, Outer - Front Compressor |
72-34-09 |
JT8D |
| 662613 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 662643 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 664209 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 664405 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 664643 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 664644 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 664840 |
Case, Diffuser |
72-37-01 |
JT8D |
| 665590 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 665711 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 665752 |
Shroud, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 665772 |
Shroud Assy, 2nd Stage |
72-53-56 |
JT8D |
| 665993 |
Case, Diffuser |
72-37-01 |
JT8D |
| 666654-001 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 666655-01 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 666742 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 666743 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 667487 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 667488 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 667993 |
Inner Outlet Duct |
72-51-22 |
JT8D |
| 667996 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 667997 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 667998 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 668906 |
Disk-Compressor, 6th Stage |
72-33-37 |
JT8D |
| 669424 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 669426 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 669472 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 671804 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 671904 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 672904 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 673107 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 673108 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 673109 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 673110 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 673111 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 673112 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 673146 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 673147 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 674527 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 674530 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 674764 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 674890 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 676372 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 676392 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 676393 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 676472 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 676822 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 676918 |
Damper, No. 5 Bearing |
72-41-21 |
JT8D |
| 676919 |
Plate-Retaining, No. 5 Bearing |
72-41-22 |
JT8D |
| 676923 |
Support, No. 5 Bearing Seal |
72-52-11 |
JT8D |
| 676952 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 676954 |
Heatshield, Inner-No. 4 & 5 Bearing |
72-41-01 |
JT8D |
| 678030 |
Duct Segment, Fan Turbine Inner |
72-71-05 |
JT8D |
| 678181 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 678182 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 678187 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 678202 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 678697 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 690005 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D |
| 690620 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 690790 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 690791 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 690792 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 690793 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 690795 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 690796 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 690882 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 690883 |
Air Seal, Compressor - 2nd Stage |
72-33-16 |
JT8D |
| 690908 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 691334 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 691344 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 691834 |
Oil Seal Ring, No. 4 Bearing |
72-37-08 |
JT8D |
| 692304 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 692404 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 692424 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 692439 |
Case, Diffuser |
72-37-01 |
JT8D |
| 692440 |
Case, Diffuser |
72-37-01 |
JT8D |
| 692504 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 692595 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 692799 |
Case, Diffuser |
72-37-01 |
JT8D |
| 692877 |
Case, Diffuser |
72-37-01 |
JT8D |
| 692894 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 692986-001 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 693177 |
Oil Nozzle, No. 2 & No. 3 Bearing |
72-34-09 |
JT8D |
| 694286 |
Case, Diffuser |
72-37-01 |
JT8D |
| 694287 |
Case, Diffuser |
72-37-01 |
JT8D |
| 695304 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 695587 |
Seal, 7th Stage |
72-36-22 |
JT8D |
| 695588 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 695607 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 696564 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 696726 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 696735 |
Support-Airduct, Cooling |
72-51-01 |
JT8D-200 |
| 696801 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 696858 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 696859 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 697115 |
Case, Turbine Front |
72-51-02 |
JT8D |
| 697372 |
Spacer, No. 3 Bearing |
72-34-36 |
JT8D |
| 697373 |
Seal Assy, No. 3 Bearing |
72-34-40 |
JT8D |
| 697417 |
Case, Diffuser |
72-37-01 |
JT8D |
| 697418 |
Case, Diffuser |
72-37-01 |
JT8D |
| 697488-001 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 697533 |
Case, Diffuser |
72-37-01 |
JT8D |
| 697534 |
Case, Diffuser |
72-37-01 |
JT8D |
| 697666 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 697667 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 697724 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 697734 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 698145 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 698147 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 698148 |
Seal Assy, No. 3 Bearing |
72-34-40 |
JT8D |
| 698149 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 698157 |
Seal Assy, No. 3 Bearing |
72-34-40 |
JT8D |
| 698307 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 698604 |
Shaft, Turb - Rear Comp Drive (T1) |
72-52-03 |
JT8D |
| 698623 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 698624 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 698927 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D |
| 699013 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 699113 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 699155 |
Housing Assy, No. 3 Bearing |
72-34-32 |
JT8D |
| 699208 |
Disk-Compressor, 8th Stage |
72-36-42 |
JT8D |
| 699309 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 699310 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 699311 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 699312 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 699332 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 699707 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 701308 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 701344 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 701407 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 701408 |
Disk-Compressor, 8th Stage |
72-36-42 |
JT8D |
| 701410 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 701411 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 701412 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 701507 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 701509 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 701996 |
Case, Diffuser |
72-37-01 |
JT8D |
| 701997 |
Case, Diffuser |
72-37-01 |
JT8D |
| 701998 |
Case, Diffuser |
72-37-01 |
JT8D |
| 702030 |
Case, Diffuser |
72-37-01 |
JT8D |
| 702035 |
Case, Diffuser |
72-37-01 |
JT8D |
| 702382 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 702482 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 702689 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 702694 |
Duct Assy, Combustion Chamber |
72-51-15 |
JT8D |
| 702697 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 702698 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 702700 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 703031 |
Inner Outlet Duct |
72-51-22 |
JT8D |
| 703973 |
Duct Assy, Combustion Chamber |
72-51-21 |
JT8D |
| 704473 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 704474 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 704484 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 704493 |
Stator, 3rd Stage |
72-33-54 |
JT8D |
| 706526 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 706537 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 706891 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 707471 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 707472 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 708303 |
Case, Diffuser |
72-37-01 |
JT8D |
| 708304 |
Case, Diffuser |
72-37-01 |
JT8D |
| 708305 |
Case, Diffuser |
72-37-01 |
JT8D |
| 708322 |
Case, Diffuser |
72-37-01 |
JT8D |
| 708323 |
Case, Diffuser |
72-37-01 |
JT8D |
| 708468 |
Duct Segment, Fan Turbine Inner |
72-71-05 |
JT8D |
| 708692 |
Shroud Assy, 2nd Stage |
72-53-56 |
JT8D |
| 708852 |
Shroud, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 709134 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 709135 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 709136 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 710128 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 711224 |
Damper, No. 5 Bearing |
72-41-21 |
JT8D |
| 711366 |
Case, Turbine Front |
72-51-02 |
JT8D |
| 711573 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 711574 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 712537 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 712538 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 712691 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 712768 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 712770 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 713105 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D |
| 713669 |
Case, Diffuser |
72-37-01 |
JT8D |
| 714048 |
Fan Case, Front |
72-33-66 |
JT8D |
| 714074 |
Fan Case, Front |
72-33-66 |
JT8D |
| 714081 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 714091 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 714472 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 714473 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 714485 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 714486 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 716117 |
Duct-Fan, Diffuser, Outer |
72-38-01 |
JT8D |
| 716847 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 716848 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 716851 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 716853 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 716854 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 716855 |
Spacer-Compressor, 4 to 5th Stage |
72-33-43 |
JT8D |
| 716856 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 717277 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 717278 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 717279 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 717312 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 717313 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 717608 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 717623 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 717680 |
Seal, 7th Stage |
72-36-22 |
JT8D |
| 717708 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 719837 |
Tube-Seal, Rear Compressor |
72-36-19 |
JT8D |
| 725526 |
Plate-Retaining, No. 5 Bearing |
72-41-22 |
JT8D |
| 725527 |
Plate-Retaining, No. 5 Bearing |
72-41-22 |
JT8D |
| 725529 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 725533 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 725535 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 725537 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 725822 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 726222 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 726226 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 726227 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 726230 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 726448 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 726547 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 726554 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 726555 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 726556 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 726557 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 726558 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 726559 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 726560 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 726561 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 727311 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 727314 |
Housing Assy, No. 5 Bearing |
72-41-24 |
JT8D |
| 727440 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727442 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727443 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727444 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727445 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727446 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727696 |
Fan Case, Front |
72-33-66 |
JT8D |
| 727697 |
Fan Case, Front |
72-33-66 |
JT8D |
| 727719 |
Rear Support, Combustion Chamber |
72-51-21 |
JT8D |
| 727720 |
Duct Assy, Combustion Chamber |
72-51-15 |
JT8D |
| 727723 |
Oil Seal Ring, No. 4 Bearing |
72-37-08 |
JT8D |
| 727739 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727740 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727742 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727744 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727745 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727748 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727749 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727750 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727751 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727752 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727753 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727754 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727755 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727756 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727757 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727758 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727759 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727760 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727762 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727765 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727766 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727776 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727777 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727778 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727779 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727780 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727781 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727782 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727790 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727793 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727794 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727795 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727796 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727797 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727798 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727799 |
Case, Diffuser |
72-37-01 |
JT8D |
| 727850 |
Case, Diffuser |
72-37-01 |
JT8D |
| 728327 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 728329 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 728729 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 728730 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 728732 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 728733 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 728734 |
Spacer-Compressor, 11 to 12th Stage |
72-36-14 |
JT8D |
| 728735 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 728829 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 728912 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 729259 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 729260-002 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 729570 |
Spacer, No. 3 Bearing |
72-34-36 |
JT8D |
| 729917 |
Case, Diffuser |
72-37-01 |
JT8D |
| 730202 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 730302 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 730317 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 730402 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 730413 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 730414 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 734224 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 734234 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 734244 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 734304 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 734324 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 734334 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 734344 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 734404 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 734504 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 734604 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 734704 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 734804 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 734948 |
Heat Shield, No. 5 Bearing |
72-52-13 |
JT8D |
| 735844 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 735845 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 735846 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 735850 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 735851 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 735852 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 735854 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 735855 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 735856 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 735883 |
Inner Outlet Duct |
72-51-22 |
JT8D |
| 735884 |
Duct Assy, Combustion Chamber |
72-51-15 |
JT8D |
| 737229 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 738254 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 738308 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 738311 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 739509 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 739836 |
Case, Diffuser |
72-37-01 |
JT8D |
| 739837 |
Case, Diffuser |
72-37-01 |
JT8D |
| 740104 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 740204 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 740304 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 740502 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 740694 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 740826 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 741219 |
Air Seal Ring, Turb. - 4th Stage Outer |
72-53-61 |
JT8D |
| 741574 |
Case, Diffuser |
72-37-01 |
JT8D |
| 742501 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 743301 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 743804 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 743824 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 743834 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 743904 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 744304 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 744324 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 744334 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 744344 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 744424 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 744444 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 744504 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 744524 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 744534 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 744544 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 744704 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 744724 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 744734 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 744757 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 744758 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 744762 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 744804 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 744904 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 745004 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 745104 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 745204 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 745304 |
Hub, Rear - Front Compressor, 4th Stage |
72-33-35 |
JT8D |
| 745404 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 745533 |
Disk-Compressor, 3rd Stage |
72-33-34 |
JT8D |
| 745534 |
Air Seal, Compressor - 2nd Stage |
72-33-16 |
JT8D |
| 745648 |
Case, Diffuser |
72-37-01 |
JT8D |
| 745702 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 745704 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 745705 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D |
| 745706 |
Disk-Compressor, 6th Stage |
72-33-37 |
JT8D |
| 745803 |
Disk-Compressor, 3rd Stage |
72-33-34 |
JT8D |
| 745902 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 746002 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 746003 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 746059 |
Duct Assy, Combustion Chamber |
72-51-15 |
JT8D |
| 746802 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 747437 |
Case, Diffuser |
72-37-01 |
JT8D |
| 748285 |
Combustion Chamber |
72-41-14 |
JT8D |
| 748286 |
Combustion Chamber |
72-41-14 |
JT8D |
| 748461 |
Duct Assy, Combustion Chamber |
72-51-15 |
JT8D |
| 748462 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 748463 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 748464 |
Case, Diffuser |
72-37-01 |
JT8D |
| 748466 |
Case, Diffuser |
72-37-01 |
JT8D |
| 748467 |
Case, Diffuser |
72-37-01 |
JT8D |
| 748469 |
Case, Diffuser |
72-37-01 |
JT8D |
| 748540 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 748541 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 748608 |
Disk-Compressor, 8th Stage |
72-36-42 |
JT8D |
| 749362 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 749363 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 749364 |
Spacer-Compressor, 7 to 8th Stage |
72-36-11 |
JT8D |
| 749365 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 749612 |
Inner Shield, No. 4 and 5 Bearing |
72-41-02 |
JT8D-200 |
| 749684 |
Case, Diffuser |
72-37-01 |
JT8D |
| 749701 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 749801 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 750001 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 750101 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 750222 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 750309 |
Case, Diffuser |
72-37-01 |
JT8D |
| 750336 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750337 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750338 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750340 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750342 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750343 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750344 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750345 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750346-001 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750347 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750348 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750349 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 750376 |
Case, Diffuser |
72-37-01 |
JT8D |
| 750377 |
Case, Diffuser |
72-37-01 |
JT8D |
| 750378 |
Case, Diffuser |
72-37-01 |
JT8D |
| 750379 |
Case, Diffuser |
72-37-01 |
JT8D |
| 750385 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 750386 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 750387 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 751161 |
Case, Diffuser |
72-37-01 |
JT8D |
| 751162 |
Case, Diffuser |
72-37-01 |
JT8D |
| 751163 |
Case, Diffuser |
72-37-01 |
JT8D |
| 751164 |
Case, Diffuser |
72-37-01 |
JT8D |
| 751165 |
Case, Diffuser |
72-37-01 |
JT8D |
| 751304 |
Hub-Turbine, 4th Stage |
72-53-18 (19) |
JT8D |
| 752174 |
Case, Diffuser |
72-35-01 |
JT8D |
| 752175 |
Case, Diffuser |
72-37-01 |
JT8D |
| 752176 |
Case, Diffuser |
72-37-01 |
JT8D |
| 752181 |
Case, Diffuser |
72-37-01 |
JT8D |
| 752193 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 752401 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 753544 |
Spacer-Compressor, 11 to 12th Stage |
72-36-11 |
JT8D |
| 753545 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 753799 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 753804 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 753855 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 753856 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 753858 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 753859 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 754234 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 754555 |
Case, Diffuser |
72-37-01 |
JT8D |
| 754556 |
Case, Diffuser |
72-37-01 |
JT8D |
| 754557 |
Case, Diffuser |
72-37-01 |
JT8D |
| 754558 |
Case, Diffuser |
72-37-01 |
JT8D |
| 754559 |
Case, Diffuser |
72-37-01 |
JT8D |
| 754560 |
Case, Diffuser |
72-37-01 |
JT8D |
| 754561 |
Case, Diffuser |
72-37-01 |
JT8D |
| 754856 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 754860 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 754862 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 754866 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 754925-001 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 754945 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 755164 |
Fan Case, Front |
72-33-66 |
JT8D |
| 755166 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 756776 |
Duct Segment, Fan Turbine Inner |
72-71-05 |
JT8D |
| 756854 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 757003 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 757103 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 757244 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 757245 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 757503 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 758275 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D-200 |
| 760266 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 760267 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 760297 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 760402 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 760502 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 760707 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 761010 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 761812 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 761973 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 761974 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 761983 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 761984 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 761993 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 761994 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 762064 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 762065 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 762083 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 762084 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 762136 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 762137 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 762138 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 762139 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 762140 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 762142 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 762143 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 762144 |
Spacer-Compressor, 5 to 6th Stage |
72-33-45 |
JT8D |
| 762145 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 762270 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 762336 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 762337 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 762338 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 762339 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 762340 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 762342 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 762420 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 762425 |
Air Seal-Turbine, 2nd Stage |
72-53-26 |
JT8D-200 |
| 762438 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 762442 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 762443 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 762444 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 762445 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 762446 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 762448 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 762462 |
Exhaust Case, Turbine |
72-54-01 |
JT8D |
| 762467 |
Spacer-Compressor, 1 to 2nd Stage |
72-33-41 |
JT8D |
| 762468 |
Spacer-Compressor, 3 to 4th Stage |
72-33-41 |
JT8D |
| 762604 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 762725 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 762726 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 762727 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 762728 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 762729 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 765152 |
Duct, Outer - Front Compressor |
72-34-07 |
JT8D |
| 765274 |
Fan Case, Front |
72-33-66 |
JT8D |
| 765276 |
Fan Case, Front |
72-33-66 |
JT8D |
| 765278 |
Fan Case, Front |
72-33-66 |
JT8D |
| 765469 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 765471 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 765754 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 765758 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 765759 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 765784 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 766007 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 766231 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D-200 |
| 766293 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 766295 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 766419 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 767197 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 767279 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 767284 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 767285 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 767286 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 767287 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 767288 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 767289 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 767290 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 767425 |
Support Assy, No. 4 Bearing |
72-37-08 |
JT8D-200 |
| 767441 |
Seal Assy, No. 4 Bearing |
72-36-80 |
JT8D-200 |
| 767448 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D-200 |
| 767601 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 768453 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 768877 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 769047 |
Hub-Turbine, 4th Stage |
72-53-18 (19) |
JT8D |
| 769104 |
Disk-Turbine, 4th Stage |
72-53-15 |
JT8D |
| 769128 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 769311 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 769312 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 769411 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 769412 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 769511 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 769512 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 769588 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 769611 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 769612 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 769703 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 769722 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 769732 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 769777 |
Case, Diffuser |
72-37-01 |
JT8D |
| 769778 |
Case, Diffuser |
72-37-01 |
JT8D |
| 769779 |
Case, Diffuser |
72-37-01 |
JT8D |
| 769780 |
Case, Diffuser |
72-37-01 |
JT8D |
| 769782 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 769783 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 769822 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 769832 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 769842 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 770003 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 770122 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 770178 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770203 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 770222 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 770303 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 770310 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 770322 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 770373 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770374 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770375 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770376 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770377 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770378 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770379 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770382 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770383 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770384 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770385 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770386 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770387 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770388 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770389 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770390 |
Case, Diffuser |
72-37-01 |
JT8D |
| 770403 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 770410 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 770510 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 770603 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 770610 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 770703 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 771013 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 771098 |
Heatshield, Inner-No. 4 & 5 Bearing |
72-41-01 |
JT8D |
| 771122 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 771242 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 771605 |
Compressor Inlet Duct |
72-23-06 |
JT8D-200 |
| 771868 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 771896 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 772061 |
Spacer, No. 3 Bearing |
72-34-36 |
JT8D |
| 772062 |
Seal Assy, No. 3 Bearing |
72-34-40 |
JT8D |
| 772293 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 772402 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D-200 |
| 772509 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 772510 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 772511 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 772592 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D-200 |
| 772803 |
Disk-Compressor, 3rd Stage |
72-33-34 |
JT8D-200 |
| 772805 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D-200 |
| 772806 |
Disk-Compressor, 6th Stage |
72-33-37 |
JT8D-200 |
| 772903 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 773002 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 773067 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 773068 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 773108 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 773109 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 773110 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 773111 |
Outer Outlet Duct |
72-51-23 |
JT8D |
| 773168 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 773169 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 773170 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 773172 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 773173 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 773174 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 773177 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 773178 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 773179 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 773180 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 773182 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 773183 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 773184 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 773186 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 773774 |
Case, Diffuser |
72-37-01 |
JT8D |
| 774338 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 774407 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 774879 |
Duct Segment, Fan Exh, R, Rear |
72-55-08 |
JT8D |
| 775437 |
Duct Assy, Fan Diffuser |
72-38-01 |
JT8D-200 |
| 775444 |
Duct, Fan Exhaust Outer Rear |
72-55-04 |
JT8D-200 |
| 775782 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 775956 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 776151 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 776367 |
Liner Segment - Fan Exhaust, Upper |
72-54-31 |
JT8D-200 |
| 776369 |
Liner Segment - Fan Exhaust, Lower |
72-54-31 |
JT8D-200 |
| 776374 |
Duct, Fan Exhaust Intmd Inner |
72-54-11 |
JT8D-200 |
| 776482 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 776613 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D-200 |
| 776642 |
Duct, Fan Exhaust Inner Rear |
72-55-08 |
JT8D-200 |
| 777148 |
Case, Turbine Front |
72-51-02 |
JT8D-200 |
| 777190 |
Support-Front Accessory Drive |
72-21-01 |
JT8D-200 |
| 777466 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D-200 |
| 777543 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D-200 |
| 777546 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D-200 |
| 777603 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D-200 |
| 777604 |
Disk-Turbine, 4th Stage |
72-53-18 |
JT8D-200 |
| 777622 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D-200 |
| 777697 |
Duct Guide, Fan & Turb. Exhaust |
72-54-12 |
JT8D |
| 777704 |
Hub, Front - Rear Compressor |
72-33-35 |
JT8D-200 |
| 777738 |
Air Seal Ring, Turb. - 3rd Stage |
72-53-57 |
JT8D-200 |
| 777739 |
Air Seal Ring, Turb. - 4th Stage |
72-53-58 |
JT8D-200 |
| 777740 |
Air Seal Ring, Turb. - 2nd Stage Outer |
72-53-59 |
JT8D-200 |
| 777741 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D-200 |
| 777742 |
Air Seal Ring, Turb. - 4th Stage Outer |
72-53-61 |
JT8D-200 |
| 777851 |
Inner Shield, No. 4 and 5 Bearing |
72-41-02 |
JT8D-200 |
| 777855 |
Hub-Turbine, 4th Stage |
72-53-19 |
JT8D-200 |
| 777856 |
Housing Assy, No. 3 Bearing |
72-34-32 |
JT8D |
| 778819 |
Case, Turbine Exhaust |
72-54-01 |
JT8D-200 |
| 778857 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 778870 |
Case, Turbine Front |
72-51-02 |
JT8D |
| 778901 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 778904 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 778965 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 778966 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 778969 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D-200 |
| 779174 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 779180 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 779181 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 779183 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 779184 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 779185 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 779193 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 779729 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 779731 |
Seal Assy, No. 3 Bearing |
72-34-40 |
JT8D |
| 779732 |
Seal Assy, No. 3 Bearing |
72-34-40 |
JT8D |
| 780029 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780030 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780032 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780033 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780034 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780035 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780036 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780037 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780038 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780039 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780040 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780042 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780043 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780044 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780045 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780046 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780047 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780048 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780049 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780103 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780105 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780110 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780111 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780112 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780113 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780114 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780115 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780117 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780118 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780119 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780120 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780122 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780124 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780125 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780126 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780129 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780130 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780132 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780133 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780135 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780136 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780137 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780138 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780139 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780140 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780142 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780143 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780144 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780145 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780146 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780147 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780148 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780149 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780203 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780204 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780205 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780206 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780210 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780211 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780212 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780213 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780214 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780215 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780216 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780217 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780218 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780219 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780220 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780222 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780223 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780224 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780225 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780227 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780228 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780262 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780310 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780311 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780313 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780317 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780318 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780328 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 780329 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 780330 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 780557 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D-200 |
| 780575 |
Spacer-Turb, Air Sealing Ring |
72-53-52 |
JT8D-200 |
| 780746 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 780771 |
Spacer, Turbine Rotor |
72-53-21 |
JT8D |
| 780795 |
Spacer-Compressor, 8 to 9th Stage |
72-36-12 |
JT8D |
| 780796 |
Spacer-Compressor, 9 to 10th Stage |
72-36-13 |
JT8D |
| 780797 |
Spacer-Compressor, 10 to 11th Stage |
72-36-14 |
JT8D |
| 780798 |
Spacer-Compressor, 11 to 12th Stage |
72-36-15 |
JT8D |
| 780799 |
Spacer-Compressor, 12 to 13th Stage |
72-36-16 |
JT8D |
| 780853 |
Combustion Chamber |
72-41-14 |
JT8D |
| 780854 |
Combustion Chamber |
72-41-14 |
JT8D |
| 780909 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780910 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780911 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780912 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780913 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780914 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780915 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780916 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780917 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780918 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780919 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780920 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780921 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780922 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780923 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780924 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780925 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780926 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780927 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780928 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780929 |
Case, Diffuser |
72-37-01 |
JT8D |
| 780930 |
Case, Diffuser |
72-37-01 |
JT8D |
| 781025 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 781026 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 781027 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 781028 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 781029 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 781030 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 781031 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 781032 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 781033 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 781809 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 781964 |
Oil Seal Ring, No. 4 Bearing |
72-37-08 |
JT8D |
| 781965 |
Oil Seal Ring, No. 4 Bearing |
72-37-08 |
JT8D |
| 781966 |
Oil Seal Ring, No. 4 Bearing |
72-37-08 |
JT8D |
| 782109 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 782180 |
Case, Diffuser |
72-37-01 |
JT8D |
| 782209 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 782229 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 782309 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 782868 |
Support, Turbine Stator |
72-51-01 |
JT8D-200 |
| 783038 |
Case, Diffuser |
72-37-01 |
JT8D |
| 783046 |
Case, Diffuser |
72-37-01 |
JT8D |
| 783622 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D-200 |
| 783623 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 783624 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 783768 |
Case, Turbine Front |
72-51-02 |
JT8D |
| 783914 |
Case, Diffuser |
72-37-01 |
JT8D |
| 783915 |
Case, Diffuser |
72-37-01 |
JT8D |
| 783916 |
Case, Diffuser |
72-37-01 |
JT8D |
| 783917 |
Case, Diffuser |
72-37-01 |
JT8D |
| 783918 |
Case, Diffuser |
72-37-01 |
JT8D |
| 783919 |
Case, Diffuser |
72-37-01 |
JT8D |
| 783932 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 783933 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 783934 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 783935 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 783936 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 783937 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 783938 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 783939 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 783940 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 783970 |
Outlet Duct Assy |
72-51-15 |
JT8D |
| 784024 |
Duct Assy, Combustion Chamber |
72-51-15 |
JT8D |
| 784029 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 784054 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784058 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784059 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784066 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784079 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784087 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784088 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784089 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784090 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784091 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784092 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784097 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784098 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784104 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784106 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784126 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784140 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784141 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784142 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784143 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784144 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784145 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784146 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784147 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784148 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784155 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784157 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784158 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784159 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784160 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784161 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784167 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784185 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784186 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784187 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784188 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784189 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784190 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784191 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784192 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784193 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784194 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784195 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784196 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784197 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784209 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784210 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784239 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784240 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784241 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784242 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784243 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784244 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784245 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784253 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784254 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784255 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784256 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784257 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784259 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784264 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784265 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784266 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784267 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784268 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784269 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784270 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784271 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784272 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784273 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784274 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784275 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784276 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784277 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784278 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784279 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784280 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784281 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784282 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784285 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784286 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784287 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784375 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784376 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784377 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784378 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784379 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784380 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784381 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784382 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784383 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784384 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784385 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784386 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784424 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 784425 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 784426 |
Duct & Fairing Assy |
72-54-02 |
JT8D |
| 784509 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784510 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784511 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784513 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784514 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784515 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784516 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784517 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784518 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784519 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784520 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784670 |
Case, Turbine Exhaust |
72-54-01 |
JT8D-200 |
| 784803 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784804 |
Case, Diffuser |
72-37-01 |
JT8D |
| 784806 |
Case, Diffuser |
72-37-01 |
JT8D |
| 785030 |
Fan Case, Front |
72-33-66 |
JT8D |
| 785031 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 785424 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 785549 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 785565 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785566 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785568 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785575 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785576 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785577 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785578 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785579 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785580 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785581 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785583 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785584 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 785792 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 785818 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 785820 |
Fan Case, Front |
72-33-66 |
JT8D |
| 785841 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D-200 |
| 786217 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786218 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786219 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786220 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786221 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786222 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786223 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786224 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786225 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786226 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786227 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786228 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786229 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786230 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786231 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786232 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786233 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786234 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786235 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786236 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786237 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786238 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786239 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786240 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786241 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786242 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786243 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786244 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786245 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786246 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786247 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786248 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786249 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786250 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786251 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786255 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786256 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786257 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786322 |
Support, Turbine Stator |
72-51-01 |
JT8D-200 |
| 786408 |
Hub, Front - Rear Compressor |
72-36-17 |
JT8D |
| 786481 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 786483 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 786484 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 786519 |
Case, Diffuser |
72-37-01 |
JT8D |
| 786715 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D-200 |
| 786722 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 786822 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 787008 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 787202-001 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 787204 |
Ring, Air Seal, Turbine - 2nd Stage |
72-53-56 |
JT8D |
| 787206 |
Air Seal Ring, Turb. - 4th Stage Outer |
72-53-61 |
JT8D |
| 787208 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 787222 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 787232 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 787308 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 787383 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 787384 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 787404 |
Disk-Turbine, 4th Stage |
72-53-18 |
JT8D-200 |
| 787408 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 787483 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 787484 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 787493 |
Shroud Assy, 3rd Stage |
72-53-57 |
JT8D |
| 787494 |
Shroud Assy, 4th Stage |
72-53-58 |
JT8D |
| 787508 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 787645 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 787753 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787754 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787755 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787756 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787757 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787758 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787759 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787760 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787761 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787762 |
Case, Diffuser |
72-37-01 |
JT8D |
| 787763 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 787765 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 787766 |
Support, Turbine Stator |
72-51-01 |
JT8D |
| 787776 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 787786 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 787787 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 787788 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 787789 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 787792 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 787797 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 787798 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 787799 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 788358 |
Heatshield, Inner-No. 4 & 5 Bearing |
72-41-01 |
JT8D |
| 788608 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 788708 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 788732 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D |
| 788808 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 788908 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 788929 |
Duct, Fan Exhaust Outer Rear |
72-55-04 |
JT8D-200 |
| 789408 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 789447 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D-200 |
| 789448 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D-200 |
| 789508 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 789554 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 789556 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 789608 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 789746 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 789747 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 789748 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 789749 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 789750 |
Spacer-Compressor, 4 to 5th Stage |
72-33-44 |
JT8D |
| 789752 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 790530 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 790531 |
Fan Case, Front |
72-33-66 |
JT8D |
| 790736 |
Fan Case, Front |
72-33-66 |
JT8D |
| 790737 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 790738 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 790739 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 790740 |
Fan Case, Front |
72-33-66 |
JT8D |
| 790741 |
Fan Case, Front |
72-33-66 |
JT8D |
| 790742 |
Fan Case, Front |
72-33-66 |
JT8D |
| 790743 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 790744 |
Fan Case, Front |
72-33-66 |
JT8D |
| 790745 |
Fan Case, Rear |
72-33-67 |
JT8D |
| 790746 |
Fan Case, Front |
72-33-66 |
JT8D |
| 790747 |
Fan Case, Front |
72-33-66 |
JT8D |
| 790804 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 790832 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 791045 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 791047 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 791304 |
Disk-Turbine, 4th Stage |
72-53-18 |
JT8D-200 |
| 791401 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 791501 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 791576 |
Spacer-Turb, Air Sealing Ring |
72-53-52 |
JT8D-200 |
| 791601 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 791701 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 791801 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 791838 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 791946 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 791947 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 792038 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 792090 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 792223 |
Housing Assy, No. 6 Bearing |
72-54-17 |
JT8D |
| 792728 |
Case, Turbine Front |
72-51-02 |
JT8D |
| 792801 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 792877 |
Inner Shield, No. 4 and 5 Bearing |
72-41-02 |
JT8D-200 |
| 793073 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 793163 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D-200 |
| 793935 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 793937 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 793946 |
Case, Diffuser |
72-37-01 |
JT8D |
| 794203 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D |
| 794602 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 794791 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 794886 |
Duct Assy, Fan Diffuser, Right |
72-71-02 |
JT8D |
| 794887 |
Duct Assy, Fan Diffuser, Left |
72-71-02 |
JT8D |
| 794972 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 794974 |
Stator, 4th Stage |
72-33-55 |
JT8D |
| 794982 |
Stator, 2nd Stage |
72-33-53 |
JT8D |
| 795059 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 795147 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 795526 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 795528 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 795603 |
Disk-Turbine, 3rd Stage |
72-53-17 |
JT8D |
| 796348 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 796761 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 796766 |
Spacer-Compressor |
72-36-11 |
JT8D-200 |
| 796767 |
Spacer-Compressor |
72-36-12 |
JT8D-200 |
| 796768 |
Spacer-Compressor |
72-36-13 |
JT8D-200 |
| 797096 |
Heat Shield, No. 5 Bearing |
72-52-13 |
JT8D |
| 797594 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 797938 |
Hub, Front - Rear Compressor |
72-36-42 |
JT8D-200 |
| 798155 |
Air Seal-Turbine, 2nd Stage |
72-53-26 |
JT8D-200 |
| 798160 |
Air Seal Ring, Turb. - 2nd Stage Outer |
72-53-59 |
JT8D-200 |
| 798162 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D-200 |
| 798164 |
Air Seal Ring, Turb. - 4th Stage Outer |
72-53-61 |
JT8D-200 |
| 798170 |
Housing Assy, No. 4 Bearing |
72-37-07 |
JT8D-200 |
| 798189 |
Air Seal Ring, Turb. - 2nd Stage Outer |
72-53-59 |
JT8D |
| 798235 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 798278 |
Air Seal Ring, Turb. - 2nd Stage Outer |
72-53-59 |
JT8D |
| 798279 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 798330 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D |
| 798509 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 798512 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 798630 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 798636 |
Duct Assy, Fan Diffuser |
72-38-01 |
JT8D-200 |
| 798808 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 798841 |
Support, Turbine Stator |
72-51-01 |
JT8D-200 |
| 798968 |
Spacer, No. 3 Bearing |
72-34-36 |
JT8D |
| 798975 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 799055 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799056 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799057 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799059 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799060 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799062 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799063 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799064 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799069 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799070 |
Case, Diffuser |
72-37-01 |
JT8D |
| 799504 |
Hub, Rear - Front Compressor |
72-33-35 |
JT8D |
| 799773 |
Disk-Compressor, 3rd Stage |
72-33-34 |
JT8D |
| 799865 |
Support Assy, No. 4 Bearing |
72-37-08 |
JT8D-200 |
| 800115 |
Disk-Compressor, 1.5 Stage |
72-33-32 |
JT8D-200 |
| 800398 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D-200 |
| 800502 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D-200 |
| 800503 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D-200 |
| 800538 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 800754-01 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 800804 |
Disk-Turbine, 4th Stage |
72-53-18 |
JT8D-200 |
| 801138 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 801139 |
Spacer-Compressor, 3 to 4th Stage |
72-33-43 |
JT8D |
| 801143 |
Spacer-Compressor |
72-36-11 |
JT8D-200 |
| 801144 |
Spacer-Compressor |
72-36-12 |
JT8D-200 |
| 801145 |
Spacer-Compressor |
72-36-13 |
JT8D-200 |
| 801148 |
Spacer-Compressor |
72-36-11 |
JT8D-200 |
| 801334 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D-200 |
| 801931 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 801933 |
Support, No. 5 Bearing Seal |
72-52-11 |
JT8D |
| 801968 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D-200 |
| 802091 |
Spacer, No. 3 Bearing |
72-34-36 |
JT8D |
| 802097 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 802105 |
Disk-Compressor, 5th Stage |
72-33-36 |
JT8D-200 |
| 802107 |
Heatshield, Inner-No. 4 & 5 Bearing |
72-41-01 |
JT8D |
| 802183 |
Liner Segment - Fan Exhaust, Upper |
72-54-31 |
JT8D-200 |
| 802185 |
Liner Segment - Fan Exhaust, Lower |
72-54-31 |
JT8D-200 |
| 802464 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 802466 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 802522 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 802691 |
Heat Shield, No. 5 Bearing |
72-52-13 |
JT8D |
| 802710 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 802722 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 802746 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D |
| 802812 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D |
| 802814 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D |
| 803114 |
Combustion Chamber |
72-41-14 |
JT8D-200 |
| 803115 |
Combustion Chamber |
72-41-14 |
JT8D-200 |
| 803122 |
Disk-Turbine, 2nd Stage |
72-53-16 |
JT8D |
| 803142-01 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 803143-01 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 803276-01 |
Liner Segment - Rear Compressor |
72-34-01 |
JT8D-200 |
| 803277-01 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 803290 |
Support-Front Accessory Drive |
72-21-01 |
JT8D-200 |
| 803569 |
Support, No. 5 Bearing Seal |
72-52-11 |
JT8D |
| 803605 |
Support-Front Accessory Drive |
72-21-01 |
JT8D-200 |
| 803614 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 803615 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 803616 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 803617 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 803618 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D |
| 803619 |
No. 4 1/2 & 6 Shield and Tube Assy |
72-53-30 |
JT8D-200 |
| 803658-01 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 803750-001 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 803782 |
Combustion Chamber |
72-41-14 |
JT8D |
| 803783 |
Combustion Chamber |
72-41-14 |
JT8D |
| 803794 |
Combustion Chamber |
72-41-14 |
JT8D |
| 803795 |
Combustion Chamber |
72-41-14 |
JT8D |
| 803912 |
Plate-Retaining, No. 5 Bearing |
72-41-22 |
JT8D |
| 803913 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D-200 |
| 803917 |
Inner Shield, No. 4 and 5 Bearing |
72-41-02 |
JT8D-200 |
| 803919 |
Inner Shield, No. 4 and 5 Bearing |
72-41-02 |
JT8D-200 |
| 803939 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 803943 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 803996 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 804113 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D-200 |
| 804211 |
Case, Turbine Rear |
72-53-51 |
JT8D |
| 804212 |
Case, Turbine Rear |
72-53-51 |
JT8D |
| 804213 |
Disk-Compressor, 13th Stage |
72-36-47 |
JT8D |
| 804301 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 804563 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D-200 |
| 804593 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 804653 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 804655 |
Housing Assy, No. 2 Bearing |
72-34-12 |
JT8D |
| 804661 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D-200 |
| 804662 |
Air Seal-Turbine, 4th Stage |
72-53-28 |
JT8D-200 |
| 805007 |
Support Assy, No. 4 Bearing |
72-37-08 |
JT8D-200 |
| 805159 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 805163 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D |
| 805165 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D-200 |
| 805173-01 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 805175-01 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 805340 |
Spacer, No. 3 Bearing |
72-34-36 |
JT8D |
| 805369-01 |
Duct Segment, Fan Turbine Inner |
72-71-05 |
JT8D |
| 805412 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 805770 |
Support-Front Accessory Drive |
72-21-01 |
JT8D-200 |
| 805777 |
Case, Combustion Chamber Inner |
72-41-10 |
JT8D |
| 805976-01 |
Duct Assy, Fan & Turb. Exhaust |
72-55-02 |
JT8D |
| 806001 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 806101 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 806125-01 |
Duct Assy, Fan & Turb. Exhaust |
72-55-02 |
JT8D |
| 806131-01 |
Duct Assy, Fan Exhaust, Outer |
72-55-04 |
JT8D |
| 806473 |
Guide, Fan & Turbine Exh Duct |
72-55-10 |
JT8D |
| 806593 |
Spacer-Turb, Air Sealing Ring |
72-53-52 |
JT8D-200 |
| 806618-01 |
Duct Assy, Fan & Turb. Exhaust |
72-55-02 |
JT8D |
| 806675 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 806688 |
Heat Shield, No. 5 Bearing |
72-52-13 |
JT8D |
| 806748 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 806876 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 806883 |
Duct, Fan Exhaust Outer |
72-54-30 |
JT8D |
| 807090 |
Heatshield, Inner-No. 4 & 5 Bearing |
72-41-01 |
JT8D |
| 807278 |
Seal Assy, No. 3 Bearing |
72-34-40 |
JT8D |
| 807350 |
Housing Assy, Gearbox Rear |
72-61-01 |
JT8D |
| 807502 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 807728 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D-200 |
| 807749 |
Case, Turbine Rear |
72-53-51 |
JT8D |
| 807790 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 807810 |
Air Seal Ring, Turb. - 4th Stage Outer |
72-53-61 |
JT8D |
| 807842 |
Spacer, No. 3 Bearing |
72-34-36 |
JT8D |
| 808009 |
Fan Case, Front |
72-33-66 |
JT8D |
| 808011 |
Fan Case And Liner Assy |
72-33-68 |
JT8D |
| 808078 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 808113 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 808125 |
Case, Combustion Chamber Outer |
72-41-11 |
JT8D |
| 808145 |
Retaining Plate, Blade - 1st Stage |
72-33-15 |
JT8D |
| 808149-01 |
Duct Assy, Fan Exhaust, Outer |
72-55-04 |
JT8D |
| 808157-01 |
Duct Assy, Fan Exhaust, Outer |
72-55-04 |
JT8D |
| 808158-01 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 808173 |
Case, Diffuser |
72-37-01 |
JT8D |
| 808209 |
Liner Segment - Rear Compressor |
72-34-04 |
JT8D-200 |
| 808225 |
Fan Case And Liner Assy |
72-33-68 |
JT8D |
| 808230 |
Fan Case, Front |
72-33-66 |
JT8D |
| 808240 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 808243 |
Support, Rear-No. 1 Bearing |
72-23-03 |
JT8D |
| 808280 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 808558 |
Case, Turbine Rear |
72-53-51 |
JT8D |
| 808560 |
Case, Turbine Rear |
72-53-51 |
JT8D |
| 808562-01 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 808636 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 809013-01 |
Air Seal Ring, Turb. - 4th Stage |
72-53-58 |
JT8D-200 |
| 809016-01 |
Air Seal Ring, Turb. - 3rd Stage |
72-53-57 |
JT8D-200 |
| 809017 |
Ring, Air Seal, Turbine - 2nd Stage |
72-53-59 |
JT8D |
| 809019-01 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 809160 |
Case, Diffuser |
72-37-01 |
JT8D |
| 810510-01 |
Duct Segment, Fan Exh, Upper, Rear |
72-55-08 |
JT8D |
| 810511-01 |
Duct Segment, Fan Exh, Lower, Rear |
72-55-08 |
JT8D |
| 810512 |
Guide, Fan & Turbine Exh Duct |
72-55-10 |
JT8D |
| 810628 |
Duct, (TOBI) Turbine Cooling Air |
72-51-10 |
JT8D-200 |
| 810645 |
Ring Assy, Air Seal, 13th Stage |
72-37-05 |
JT8D-200 |
| 810657-01 |
Duct Assy, Fan Exhaust, Outer |
72-55-04 |
JT8D |
| 811086 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D |
| 811087 |
Housing Assy, Gearbox Front |
72-61-02 |
JT8D-200 |
| 811171-01 |
Stator, 1st Stage |
72-33-51 |
JT8D |
| 811626-01 |
Duct, Fan Exhaust Inner Duct Segments |
72-54-81 |
JT8D |
| 811935 |
Support, No. 5 Bearing Seal |
72-52-11 |
JT8D |
| 811962 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 811967 |
Air Seal Ring, Turb. - 3rd Stage Outer |
72-53-60 |
JT8D |
| 811999-01 |
Duct Segment, Fan Exh, Upper, Rear |
72-55-08 |
JT8D |
| 812023-01 |
Duct Segment, Fan Exh, Lower, Rear |
72-55-08 |
JT8D |
| 812024 |
Guide, Fan & Turbine Exh Duct |
72-55-10 |
JT8D |
| 812167-01 |
Duct Segment, Fan Exh, R, Rear |
72-55-08 |
JT8D |
| 812170-01 |
Duct Segment, Fan Exh, Upper, Rear |
72-55-08 |
JT8D |
| 812174-01 |
Duct Segment, Fan Exh, Lower, Rear |
72-55-08 |
JT8D |
| 812178-01 |
Duct Segment, Fan Exh, Upper, Rear |
72-55-08 |
JT8D |
| 812183-01 |
Duct Segment, Fan Exh, Lower, Rear |
72-55-08 |
JT8D |
| 814854 |
Case, Diffuser |
72-37-01 |
JT8D |
| 815399-01 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 815607 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D |
| 815608 |
Disk-Compressor, 8th Stage |
72-36-42 |
JT8D |
| 815609 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 815610 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D |
| 815611 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D |
| 815612 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D |
| 815707 |
Disk-Compressor, 7th Stage |
72-36-41 |
JT8D-200 |
| 815708 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 815709 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D |
| 815710 |
Disk-Compressor, 10th Stage |
72-36-44 |
JT8D-200 |
| 815711 |
Disk-Compressor, 11th Stage |
72-36-45 |
JT8D-200 |
| 815712 |
Disk-Compressor, 12th Stage |
72-36-46 |
JT8D-200 |
| 815808 |
Hub, Front - Rear Compressor, 8th Stage |
72-36-42 |
JT8D |
| 815809 |
Disk-Compressor, 9th Stage |
72-36-43 |
JT8D-200 |
| 815965 |
Air Seal-Turbine, 3rd Stage |
72-53-27 |
JT8D-200 |
| 817401 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 819133 |
Duct Guide, Fan & Turb. Exhaust |
72-54-12 |
JT8D |
| 819774-01 |
Duct Assy, Fan & Turb. Exhaust |
72-55-02 |
JT8D |
| 819827-01 |
Duct Assy, Fan & Turb. Exhaust |
72-55-02 |
JT8D |
| 819828-01 |
Duct Assy, Fan & Turb. Exhaust |
72-55-02 |
JT8D |
| 819829-01 |
Duct Assy, Fan & Turb. Exhaust |
72-55-02 |
JT8D |
| 820190 |
Housing Assy, No. 1 Bearing |
72-23-02 |
JT8D |
| 820249-01 |
Case, Turbine Rear |
72-53-51 |
JT8D-200 |
| 820325-01 |
Duct Assy, Fan Diffuser |
72-38-01 |
JT8D-200 |
| 820501 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 821302 |
Disk-Compressor, 2nd Stage |
72-33-33 |
JT8D |
| 821518 |
Hub, Rear - Rear Compressor |
72-36-18 |
JT8D-200 |
| 832201 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 844401 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 845401 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 848001 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 848101 |
Hub, Front - Front Compressor |
72-33-31 |
JT8D |
| 851085 |
Fan Case And Liner Assy |
72-33-68 |
JT8D |
| 851086 |
Fan Case And Liner Assy |
72-33-68 |
JT8D |
| 851088 |
Hub, Front - Rear Compressor |
72-36-42 |
JT8D-200 |
| 851108 |
Hub, Front - Rear Compressor |
72-36-42 |
JT8D-200 |
| 855701 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 856401 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 856501 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D |
| 856601 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D-200 |
| 856701 |
Disk-Turbine, 1st Stage |
72-52-02 |
JT8D-200 |
| |
|
|
Back To Top |
| Part No. |
Description |
|
|
| 414215 |
Disk-Compressor, 15th Stage |
|
|
| 416501 |
Disk-Turbine, 1st Stage |
|
|
| 417173 |
Tube and Heatshield Assy |
|
|
| 496801 |
Disk-Turbine, 1st Stage |
|
|
| 506966 |
Shaft-Front Compressor Drive, LPT |
|
|
| 529773 |
Shroud Assy, 3rd Stage |
|
|
| 544720 |
Support Assy, No. 5 Bearing |
|
|
| 575871 |
Support Assy, No. 5 Bearing |
|
|
| 575872 |
Support Assy, No. 5 Bearing |
|
|
| 575874 |
Support Assy, No. 5 Bearing |
|
|
| 575875 |
Support Assy, No. 5 Bearing |
|
|
| 576588 |
Tube and Heatshield Assy |
|
|
| 576602 |
Disk-Compressor, 2nd Stage |
|
|
| 617442 |
Shaft-Front Compressor Drive, LPT |
|
|
| 617443 |
Shaft-Front Compressor Drive, LPT |
|
|
| 617445 |
Shaft-Front Compressor Drive, LPT |
|
|
| 622242 |
Shaft-Front Compressor Drive, LPT |
|
|
| 622244 |
Shaft-Front Compressor Drive, LPT |
|
|
| 622245 |
Shaft-Front Compressor Drive, LPT |
|
|
| 622246 |
Shaft-Front Compressor Drive, LPT |
|
|
| 622247 |
Shaft-Front Compressor Drive, LPT |
|
|
| 622251 |
Shaft-Front Compressor Drive, LPT |
|
|
| 622379 |
Heat Shield, Comb. Chamber Clamp |
|
|
| 622382 |
Clamp, Combustion Chamber |
|
|
| 622402 |
Support, Turbine Stator |
|
|
| 622734 |
Shaft-Front Compressor Drive, LPT |
|
|
| 625948 |
Support, Turbine Stator |
|
|
| 628355 |
Combustion Chamber |
|
|
| 628356 |
Combustion Chamber |
|
|
| 628357 |
Combustion Chamber |
|
|
| 628358 |
Combustion Chamber |
|
|
| 628359 |
Combustion Chamber |
|
|
| 644701 |
Duct and Fairing Assy, Turbine Exhaust |
|
|
| 657814 |
Disk-Compressor, 14th Stage |
|
|
| 657815 |
Disk-Compressor, 15th Stage |
|
|
| 671002 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671003 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671004 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671005 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671006 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671009 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671010 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671011 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671012 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671013 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671014 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671015 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671016 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671017 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671018 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671019 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671020 |
Shaft-Front Compressor Drive, LPT |
|
|
| 671023 |
Shaft-Front Compressor Drive, LPT |
|
|
| 674828 |
Shaft-Front Compressor Drive, LPT |
|
|
| 674829 |
Shaft-Front Compressor Drive, LPT |
|
|
| 674830 |
Shaft-Front Compressor Drive, LPT |
|
|
| 694794 |
Outlet Duct, Combustion Chamber |
|
|
| 699614 |
Disk-Compressor, 14th Stage |
|
|
| 701514 |
Disk-Compressor, 14th Stage |
|
|
| 703214 |
Disk-Compressor, 14th Stage |
|
|
| 704332 |
Combustion Chamber |
|
|
| 704333 |
Combustion Chamber |
|
|
| 704334 |
Combustion Chamber |
|
|
| 704335 |
Combustion Chamber |
|
|
| 730801 |
Hub, Front - Front Compressor |
|
|
| 732083 |
Shroud Assy, 3rd Stage |
|
|
| 734873 |
Shroud Assy, 3rd Stage |
|
|
| 735114 |
Disk-Compressor, 14th Stage |
|
|
| 739201 |
Hub, Front - Front Compressor |
|
|
| 746441 |
Hub, Front - Front Compressor |
|
|
| 750414 |
Disk-Compressor, 14th Stage |
|
|
| 750415 |
Disk-Compressor, 15th Stage |
|
|
| 755107 |
Shaft-Front Compressor Drive, LPT |
|
|
| 759510 |
Support, Turbine Stator |
|
|
| 759511 |
Support, Turbine Stator |
|
|
| 765049 |
Outlet Duct, Combustion Chamber |
|
|
| 765058 |
Clamp, Combustion Chamber |
|
|
| 767394 |
Combustion Chamber |
|
|
| 767395 |
Combustion Chamber |
|
|
| 767396 |
Combustion Chamber |
|
|
| 767397 |
Combustion Chamber |
|
|
| 767398 |
Combustion Chamber |
|
|
| 767411 |
Heat Shield, Comb. Chamber Clamp |
|
|
| 767922 |
Support, Turbine Stator |
|
|
| 767923 |
Support, Turbine Stator |
|
|
| 771252 |
Outlet Duct, Combustion Chamber |
|
|
| 771253 |
Outlet Duct, Combustion Chamber |
|
|
| 771254 |
Outlet Duct, Combustion Chamber |
|
|
| 781390 |
Combustion Chamber |
|
|
| 781391 |
Combustion Chamber |
|
|
| 781393 |
Combustion Chamber |
|
|
| 781394 |
Combustion Chamber |
|
|
| 781395 |
Combustion Chamber |
|
|
| 781397 |
Combustion Chamber |
|
|
| 784364 |
Duct and Fairing Assy, Turbine Exhaust |
|
|
| 784366 |
Duct and Fairing Assy, Turbine Exhaust |
|
|
| 795314 |
Disk-Compressor, 14th Stage |
|
|
| 795315 |
Disk-Compressor, 15th Stage |
|
|
| 811901 |
Disk-Turbine, 1st Stage |
|
|
| 812001 |
Disk-Turbine, 1st Stage |
|
|
| 813801 |
Disk-Turbine, 1st Stage |
|
|
| 814201 |
Disk-Turbine, 1st Stage |
|
|
| |
|
|
Back To Top |
|
| GLOBAL SERVICES |
 |
- North America
- South America
- Europe
|
|
|
| NEWS & EVENTS |
|
|
| |
|
